FRAME Alpha Platinum Aluminum, curved top tube, Removable Integrated Battery (RIB), tapered head tube, Control Freak internal routing, magnesium rocker link, Motor Armor, Mino Link, ABP, Boost148, 12mm thru-axle, 150 travel mm (Size S); Alpha Platinum Aluminum, Removable Integrated Battery (RIB), tapered head tube, Control Freak internal routing, magnesium rocker link, Motor Armor, Mino Link, ABP, Boost148, 12mm thru-axle, 150mm travel (Size M, L,XL)
FORK RockShox 35 Gold RL, DebonAir spring, Motion Control damper, lockout, tapered steerer, 44mm offset, oversized eMTB crown, Boost110, 15mm Maxle Stealth, 160mm travel
SHOCK RockShox Deluxe Select+ RT, 230mm x 57.5mm
SHIFTER LEVER Shimano Deore M6100, 12-speed
DERAILLEUR Shimano Deore M6100, long cage
CASSETTE SunRace CSMZ800 11-51, 12 speed
CHAIN Shimano Deore M6100
WHEELS Alex MD35, tubeless compatible, 32h, 35mm width, Presta valve
TIRES Bontrager XR4 Comp, wire bead, 30 tpi, 29x2.60"
HANDLEBAR Bontrager alloy, 31.8mm, 15mm rise, 750mm width
STEM Bontrager Rhythm Comp, 31.8mm, Knock Block, 0 degree, 50mm length
BRAKES Tektro HD-M745 hydraulic disc, Tektro brake rotor, 6-bolt, 203mm
SEATPOST TranzX JD-YSP18, 100mm travel, internal routing, 31.6mm, 361mm length(Size S); length 425 mm (Size M, L, XL)
SADDLE Bontrager Arvada, steel rails, 138mm width
BATTERY Bosch PowerTube 625 Wh, intelligent system
CHARGER Bosch standard 4A, 230V, intelligent system
MOTOR Bosch Performance CX, intelligent system, magnesium motor body, 85 Nm
DISPLAY Smart system, Bosch LED remote control
WEIGHT Size M - 24.88 kg
