FRAME Alpha Platinum Aluminium, Removable Integrated Battery (RIB), tapered head tube, internal routing, Motor Armor, rocker link, fender and rack mounts, ABP, Boost148, 100mm travel
FORK SR Suntour XCR 34, air, LO R, hydraulic lockout, tapered steerer, 44mm offset, oversized eMTB crown, Boost110, 15mm bolt-on thru-axle, 100mm travel (size XS, S); 120 mm travel (Size M, L, XL)
SR Suntour Edge R SHOCK , 190mm x 45mm
SHIFTER LEVER Shimano Deore M4100, 10-speed
DERAILLEUR Shimano Deore M5120, long cage
CASSETTE Shimano Deore M4100, 11-46, 10-speed
KMC X10 CHAIN , 10-speed
WHEELS Alex MD35, tubeless compatible, 32h, 35mm width, Presta valve
TIRES Size XS, S: Bontrager XR3 Comp, wire bead, 30 tpi, 27.5x2.35"; Size M, L, XL: Bontrager XR3 Comp, wire bead, 30 tpi, 29x2.30"
HANDLEBAR Bontrager alloy, 31.8mm, 15mm rise, 720 width
STEM Bontrager alloy, 31.8mm, Blendr-compatible, 7-degree, 60mm length(size XS, S); 70 mm length (Size M, L, XL)
BRAKES Tektro HD-M275 hydraulic disc, Tektro brake rotor, 6-bolt, 203mm
SEATPOST TranzX JD-YSP18, 100mm travel, internal routing, 31.6mm, 361mm length(XS, S, M); length 425 mm (Size L, XL)
SADDLE Bontrager Arvada, steel rails, 138mm width
BATTERY Bosch PowerTube 625 Wh, intelligent system
CHARGER Bosch standard 4A, 230V, intelligent system
MOTOR Bosch Performance CX, intelligent system, magnesium motor body, 85 Nm
DISPLAY Bosch Intuvia 100, intelligent system
WEIGHT Size M - 25.23 kg
